Fork Contact Electrodes/ Micro Fork Electrodes/Customizable Products/Factory Direct
Product Description: Etched Fork Electrode / Precision Etching / Customizable / Direct from Factory We utilize advanced etching technology to provide high-precision fork electrodes. These fork electrodes are widely used in fields such as semiconductors, electronic components, touch screens, sensors, and more. Our fork electrode products can be customized based on customer requirements, offering various sizes, shapes, thicknesses, and hole densities. With our fine manufacturing processes, we ensure each electrode’s shape and dimensions meet high standards to meet rigorous application requirements. Stainless Steel: Suitable for applications requiring high strength and corrosion resistance, commonly used in high-temperature and corrosive environments. Copper Alloy: Provides excellent electrical conductivity, ideal for electronic components and high-frequency current applications. Brass: Known for good electrical conductivity and ease of machining, commonly used in precision electronic components. Aluminum Alloy: Lightweight with high strength, ideal for applications requiring both lightness and high conductivity. Manufacturing Process: The fork electrodes are produced using precision etching technology, where chemical etching removes unwanted metal parts while carefully retaining the design pattern. This process offers the following features: High Precision: Capable of processing micron-level details, ensuring precise shapes and hole diameters of the fork electrodes. No Heat Deformation: Unlike traditional mechanical machining, the etching process avoids heat deformation, ensuring product stability and consistency. Mass Production: Suitable for large-scale production, ensuring consistency across batches. Burr Control: Advanced deburring processes ensure smooth, burr-free surfaces for the electrodes. Hole Accuracy: The hole diameter control is highly precise to meet different hole size requirements.
Category:
Key Words:
Table Parameter
| Product Name | Fork Contact Electrodes / Fork-shaped Electrodes / Fork Contact Electrodes / Precision Fork Electrodes / Etched Fork Contact Plates / Fork Connectors / Etched Conductive Fork Pieces / Electrode Fork Plates / Fork Shaped Electrodes / Micro Fork Electrodes |
| Materials | Stainless Steel, Copper Alloy, Brass, Aluminum Alloy |
| Hole Diameter | 0.1mm - 5mm |
| Shape & Size | Custom shapes available, such as round, rectangular, irregular, etc. Size range from micron to millimeter scale. |
| Resistivity | Varies by material |
| Hole Density | 30%-80%, customized based on customer requirements |
| Material Thickness | 0.05mm - 2mm |
| Tolerances | ±0.05mm (Thickness), ±0.1mm (Hole Diameter) |
| Tensile Strength | ≥600MPa |
| Hardness | 50-80 HB |
| Temperature Range | -40°C to +1000°C |
| Surface Treatment | Sandblasting, Brushed, Electroplating, etc. |
| Lead Time | 7-15 days (depending on order quantity) |
Application Description
Etched fork electrodes are widely used in the following fields:
Semiconductor Industry: Used in the electrode sections of semiconductor testing equipment.
Touchscreen Industry: Used in the conductive electrode parts of touchscreens.
Electronic Components: Used in the production of precision electrodes for high-frequency current applications.
Sensors: Used in the conductive electrode parts of sensors.
Others: Also widely used in battery electrodes, electronic connectors, and other fields.
Questions and Answers
| 1.Why choose etching technology? Etching technology offers high precision and micron-level processing capabilities, allowing us to replicate complex details accurately while avoiding heat deformation seen in traditional mechanical processing. This ensures product consistency and stability. |
| 2.Can the size and shape of etched fork electrodes be customized? Yes, we provide customization services and can tailor the size and shape according to customer requirements. |
| 3.What is the thickness and tolerance control for etched fork electrodes? The thickness range is from 0.05mm to 2mm, with tolerance control of ±0.05mm (thickness) and ±0.1mm (hole diameter and pitch). |
| 4.How are samples charged? Most products are available for free sampling. For custom products or higher-cost samples, a sample fee may apply, with bulk orders priced at per-unit rates. |
| 5.What is the delivery time? The production cycle for large-scale orders is typically controlled within 5-15 days. If the delivery deadline is tight, please communicate with us in advance to discuss expedited options. |
| 6.What are your payment terms? Since this is a custom product, full payment is required in advance. We support various payment methods, including: Letter of Credit (L/C) Telegraphic Transfer (T/T) PayPal (for small orders) Western Union (for some countries) Alipay/WeChat Pay (for certain countries) Bank Transfer (for all regions) |
| 7.How do you handle non-compliant products? Before mass production, we will send you samples for confirmation. After confirming that the samples meet your specifications, we will proceed with bulk production. If the product does not meet the agreed-upon specifications, please contact us with the details. If the quality issue is our fault, we will replace the product at no additional cost. |
Factory Description
We have a full set of etching production equipment and mature processing technology. We can manufacture products in any shape with mesh sizes as small as 0.1mm, according to your requirements.
Our Advantage
Factory Direct Shipping
Our products undergo 100% QC checks before shipment, and we ensure compliance with international standards. If you require specific certifications for your target market, just let us know, and we'll meet those requirements.
Experienced Design and Manufacturing Team
We work closely with customers from the design phase to help avoid potential product flaws, ensuring both the functionality and design meet expectations.
Excellent Supply Chain Management
We can quickly adjust production schedules to meet your urgent deadlines, whether it's for large bulk orders or smaller rush orders.
OEM & ODM Support
We offer the option to print your logo or other customizations.
Strict Quality Control
Our products undergo 100% QC checks before shipment, and we ensure compliance with international standards. If you require specific certifications for your target market, just let us know, and we'll meet those requirements.
